LED indicator descriptions
Control mode
GPS signal
Manual Mode: No indicator
Best ( > 6): No indicator
ATTI. Mode: (1) (sticks not in mid-point (2))
Good ( = 6): (1)
GPS ATTI. Mode: (1) (sticks not in mid-point (2))
Bad ( = 5) : (2)
Ground Station: (1)
Worst ( < 5): (3)
Flight Attitude
Attitude good: No indicator
Attitude status bad: (3)
IMU data lost, calibrate IMU needed： (4)
Compass calibration
Horizontal calibration
(∝)
Calibration Failed
(∝)
Vertical calibration
(∝)
Abnormal Compass Data
(∝)
Low voltage alert
First level alert (∝)
Second level alert (∝)
FailSafe mode
During the FailSafe
(∝)
Errors
System Error (4)
Compass Abnormal after power on (∝)
IOC Recording
Record home-point successfully
(20)
Aircraft is in the 8m range of HP
(6)
Record forward direction successfully
(20)
Record a Point Of Interest successfully
(20)
Bluetooth
A2 Assistant is connected / disconnected to the flight control system (∝)
When the LED blinks (3), please hover or land the aircraft and wait for the white LED to go off.
When the LED blinks (3), it is not recommended to fly.
When the LED blinks (4), please contact your dealer.
