Data-link LED Introduction
Function
Introduction
Ground End
LINK-ALARM
Distance Alarm
Light on indicates distance warning.
LINK-ALARM
Network Light
Light on indicates communication is on with air end.
DATA-POWER
Power Light
Light on indicates working well.
DATA-POWER
Data Light
Light flash indicates data transmit and receive.
Air End
Link
Data Light
Light on indicates communication is on.
Power
Power Light
Light on indicates working well.
TX
Transmit Light
Light on indicates data transmit.
RX
Receive Light
Light on indicates data receive.
