dji Focus - Specifications

22
©
2015 DJI. All Rights Reserved.
Specications
General
Operating Frequency 2.415-2.473 GHz
Max Transmission Distance 100 m (outdoors and unobstructed)
Transmitter Power 14 dBm
Operating Temperature -20° to 55° C
Motor
Weight 170 g
Dimensions 90×50×26 mm
Max. Torque 0.35 Nm
Max. Speed 192 rpm
Operating Current Free current: 80 mA (@12 V)
Stall current: 2 A (@12 V)
Operating Voltage 9-16 V
Noise <25 dB (@96 rpm)
Rob Clamp Inner Diameter 15 or 19 mm
Gear 0.8 Mod, 40 Teeth
Remote Controller
Weight 745 g
Dimensions 153×86×90 mm
Battery Model: FB01-554461
LiPo
3.7 V, 1700 mAh, 6.29 Wh
