Introduction
DJI Focus is a wireless follow focus system that comprises of a remote controller and motor unit.
The low noise motor produces 25 dB of noise at 96 rpm, and has a maximum speed and torque
of 192 rpm and 0.35 Nm respectively. The system can be operated in wireless mode or cable
mode.
In the Box
Check that all of the following items are included in the package. If any items are missing,
contact DJI Support or your local DJI authorized dealer.
Remote Controller ×1
Handheld unit which controls the motor remotely.
Motor ×1
Mounted on the camera to control the lens.
Antenna ×2
Amplies the remote controller’s signal.
Motor Power Cable ×2
Connects the motor to the power supply.
Lengths: 40 cm and 75 cm.
Data Cable ×1
Used in cable mode and for rmware updates.
