dji MAVIC MINI User Manual

18
©
2019 DJI All Rights Reserved.
Mavic Mini User Manual
Attaching the Propellers
Attach the propellers with marks to the motors of the arm with marks and the unmarked propellers
to the motors of the arm without marks. Use the screwdriver to mount the propellers. Make sure the
propellers are secure.
MarksUnmarked
Flight Recorder
Flight data including flight telemetry, aircraft status information, and other parameters are
automatically saved to the internal data recorder of the aircraft. The data can be accessed using
DJI Assistant 2 for Mavic.
Propellers
There are two types of Mavic Mini propellers, which are designed to spin in dierent directions. Marks
are used to indicate which propellers should be attached to which motors. The two blades attached to
one motor are the same.
Propellers
With marks Without marks
Illustration
Mounting
Position
Attach to the motors of the arms with
marks
Attach to the motors of the arms
without marks
Use QuickShots at locations that are clear of buildings and other obstacles. Make sure that there
are no humans, animals, or other obstacles in the flight path.
Pay attention to objects around the aircraft and use the remote controller to avoid accidents with
the aircraft.
DO NOT use QuickShots in any of the following situations:
a. When the subject is blocked for an extended period or outside the line of sight.
b. When the subject is more than 50 m away from the aircraft.
c. When the subject is similar in color or pattern with the surroundings.
d. When the subject is in the air.
e. When the subject moves fast.
f. The lighting is extremely low (< 300 lux) or high (> 10,000 lux).
DO NOT use QuickShots in places that are close to buildings or where the GPS signal is weak.
Otherwise, the flight path may be unstable.
Make sure to follow local privacy laws and regulations when using QuickShots.

dji MAVIC MINI Specifications

General

Type	Quadcopter
Foldable	Yes
Product color	Black, White
Construction type	Ready-to-fly (RTF)
Maximum speed	13 m/s
Number of axis	3
Number of rotors	4 rotors
Maximum tilt angle	30 °
Maximum flight time	30 min
Maximum ascent speed	4 m/s
Maximum descent speed	3 m/s
Maximum flight altitude	3000 m
Maximum weight capacity	- kg
Maximum wind resistance	8 m/s
Horizontal hover accuracy	0.1 m
Number of propeller blades	2
Maximum pitch angular velocity	150 °/sec
Operating temperature (T-T)	0 - 40 °C
Megapixel	12 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 2720 x 1530 pixels
Maximum frame rate	60 fps
Optical sensor size	1/2.3 \
Camera shutter speed	4-1/8000 s
Supported video modes	1080p
Image formats supported	JPEG
Video formats supported	AVC, H.264, MP4, MPEG4
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	2720 x 1530 pixels
Field of view (FOV) angle	83 °
Bitrate at maximum video resolution	40 Mbit/s
Battery voltage	7.2 V
Battery capacity	2400 mAh
Transmitter battery capacity	2600 mAh
Maximum device width	160 mm
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
AC adapter power	18 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	1.5 A
AC adapter output voltage	12 V
Power consumption (transmitter) (max)	1200 mA
Cables included	Lightning, Micro-USB, RC, USB Type-C
Built-in processor	-

Weight and Dimensions

Depth	140 mm
Width	82 mm
Height	57 mm
Battery weight	100 g
Wheelbase diagonal	213 mm
Takeoff weight (max)	249 g
