Product Prole

Introduction

Featuring a Downward Vision System and Infrared Sensing System, DJI Mavic Mini can hover and y

indoors as well as outdoors and Return to Home automatically. With a fully stabilized 3-axis gimbal and

1/2.3” sensor camera, Mavic Mini shoots 2.7k video and 12 MP photos. Mavic Mini has a maximum

ight speed of 29 mph (46.8 kph) and a maximum ight time of 30 minutes.

Feature Highlights

Mavic Mini boasts a folded design and an ultralight weight of 249 g, making it easy to transport. The

Intelligent Flight Mode QuickShots provide four sub modes, which can automatically shoot and generate

dierent styles of video.

Using the advanced DJI flight controller, Mavic Mini is able to provide a safe and reliable flight

experience. The aircraft is able to automatically return to its Home Point when the remote controller

signal is lost or the battery level is low, as well as being able to hover indoors at low altitudes.

DJI's enhanced Wi-Fi technology is built into the remote controller, supporting both 2.4 GHz and 5.8 GHz

frequencies and a transmission range of up to 2.49 mi (4 km), making it possible to stream 720p video to

your mobile device.

Preparing the Aircraft

All aircraft arms are folded before the aircraft is packaged. Follow the steps below to unfold the aircraft

arms.

1. Remove the gimbal cover from the camera.

2. Unfold the front arms.

3. Unfold the rear arms.

Maximum ﬂight time was tested in an environment with no wind while ﬂying at a consistent speed

of 8.7 mph (14 kph) and the maximum ﬂight speed was tested at sea level altitude with no wind.

These values are for reference only.

The remote controller reaches its maximum transmission distance (FCC) in a wide-open area

with no electromagnetic interference at an altitude of about 400 ft (120 m). The maximum

runtime was tested in a laboratory environment. This value is for reference only.

5.8 GHz is not supported in some regions. Observe the local laws and regulations.

Other manuals for dji MAVIC MINI

Questions and Answers:

Need help?

Do you have a question about the dji MAVIC MINI and is the answer not in the manual?

General

Type	Quadcopter
Foldable	Yes
Product color	Black, White
Construction type	Ready-to-fly (RTF)
Maximum speed	13 m/s
Number of axis	3
Number of rotors	4 rotors
Maximum tilt angle	30 °
Maximum flight time	30 min
Maximum ascent speed	4 m/s
Maximum descent speed	3 m/s
Maximum flight altitude	3000 m
Maximum weight capacity	- kg
Maximum wind resistance	8 m/s
Horizontal hover accuracy	0.1 m
Number of propeller blades	2
Maximum pitch angular velocity	150 °/sec
Operating temperature (T-T)	0 - 40 °C
Megapixel	12 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 2720 x 1530 pixels
Maximum frame rate	60 fps
Optical sensor size	1/2.3 \
Camera shutter speed	4-1/8000 s
Supported video modes	1080p
Image formats supported	JPEG
Video formats supported	AVC, H.264, MP4, MPEG4
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	2720 x 1530 pixels
Field of view (FOV) angle	83 °
Bitrate at maximum video resolution	40 Mbit/s
Battery voltage	7.2 V
Battery capacity	2400 mAh
Transmitter battery capacity	2600 mAh
Maximum device width	160 mm
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
AC adapter power	18 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	1.5 A
AC adapter output voltage	12 V
Power consumption (transmitter) (max)	1200 mA
Cables included	Lightning, Micro-USB, RC, USB Type-C
Built-in processor	-
