dji MAVIC MINI User Manual

26
©
2019 DJI All Rights Reserved.
Remote Controller
Remote Controller Profile
Built into the remote controll is DJI's enhanced Wi-Fi technology, offering 2.4 GHz and 5.8 GHz*
transmission frequencies, a maximum transmission distance of 2.49 mi (4 km), and 720p video downlink
from the aircraft to DJI Fly on your mobile device. The detachable control sticks make the remote
controller easier to store. Refer to the remote controller diagram in the Product Prole section for more
information.
The built-in battery has a capacity of 2600 mAh and a maximum run time of 4.5 hours when using an
iOS device and 1 hour and 40 minutes when using an Android device. The remote controller charges
the Android device with a charging ability of 500 mA@5V. The remote controller automatically charges
Android devices.
* The MD1SD25 model remote controller can support both 2.4 GHz and 5.8 GHz. The MR1SS5 model remote
controller only supports 5.8 GHz.
Compliance Version: The remote controller is compliant with local regulations.
Control Stick Mode: The control stick mode determines the function of each control stick
movement. Three pre-programmed modes (Mode 1, Mode 2, and Mode 3) are available and
custom modes can be configured in DJI Fly. The default mode is Mode 2.
Using the Remote Controller
Powering On/Off
Press the power button once to check the current battery level.
Press once, then again and hold to turn the remote controller on or o. If the battery level is too low,
recharge before use.
Controlling the Camera
1. Record Button: Press to start/stop recording
(Video) or switch to video mode (Photo).
2. Shutter Button: Press to take photo (Photo)
or switch to photo mode (Video).
Charging the Battery
Use a Micro USB cable to connect the USB charger to the Micro USB port of the remote controller.
Record Button Shutter Button

dji MAVIC MINI Specifications

General

Type	Quadcopter
Foldable	Yes
Product color	Black, White
Construction type	Ready-to-fly (RTF)
Maximum speed	13 m/s
Number of axis	3
Number of rotors	4 rotors
Maximum tilt angle	30 °
Maximum flight time	30 min
Maximum ascent speed	4 m/s
Maximum descent speed	3 m/s
Maximum flight altitude	3000 m
Maximum weight capacity	- kg
Maximum wind resistance	8 m/s
Horizontal hover accuracy	0.1 m
Number of propeller blades	2
Maximum pitch angular velocity	150 °/sec
Operating temperature (T-T)	0 - 40 °C
Megapixel	12 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 2720 x 1530 pixels
Maximum frame rate	60 fps
Optical sensor size	1/2.3 \
Camera shutter speed	4-1/8000 s
Supported video modes	1080p
Image formats supported	JPEG
Video formats supported	AVC, H.264, MP4, MPEG4
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	2720 x 1530 pixels
Field of view (FOV) angle	83 °
Bitrate at maximum video resolution	40 Mbit/s
Battery voltage	7.2 V
Battery capacity	2400 mAh
Transmitter battery capacity	2600 mAh
Maximum device width	160 mm
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
AC adapter power	18 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	1.5 A
AC adapter output voltage	12 V
Power consumption (transmitter) (max)	1200 mA
Cables included	Lightning, Micro-USB, RC, USB Type-C
Built-in processor	-

Weight and Dimensions

Depth	140 mm
Width	82 mm
Height	57 mm
Battery weight	100 g
Wheelbase diagonal	213 mm
Takeoff weight (max)	249 g
