dji MAVIC MINI User Manual

32
©
2019 DJI All Rights Reserved.
Mavic Mini User Manual
Camera View
1. Flight Modes
P
: Tap to switch Flight modes between Position, Sport, and CineSmooth mode.
2. System Status Bar
In Flight
: Indicates aircraft ight status and displays various warning messages.
3. GPS Status
: Shows the current GPS signal strength.
4. Wi-Fi Strength
: Displays the Wi-Fi strength between the aircraft and remote controller.
5. Battery Level
80
: Shows the current battery level.
6. Battery Information
22'26
: Displays battery information such as battery temperature, voltage, and ight time.
7. System Settings
: There are Safety, Control, Camera, Transmission and About.
Safety
Flight Protection: Max Altitude, Max Distance, Auto RTH Altitude settings, and Update Home Point.
Sensors: View the IMU and compass status and start to calibrate if necessary.
Advanced Settings including Emergency Propeller Stop and Payload mode. “Emergency Only” indicates that
the motors can only be stopped mid-ight in an emergency situation such as if there is a collision, a motor
has stalled, the aircraft is rolling in the air, or the aircraft is out of control and ascending or descending very
quickly. “Anytime” indicates that the motors can be stopped mid-ight anytime once the user performs a
combination stick command (CSC). Stopping the motors mid-ight will cause the aircraft to crash.
If accessories are mounted to Mavic Mini, it is recommended to enable Payload mode for enhanced safety.
After takeo, Payload mode is enabled automatically if a payload is detected. Note that the Max Service
Ceiling above Sea Level is 1500 m and the max ight speed is limited when Payload mode is enabled.
The Find My Drone feature helps to nd the location of the aircraft on the ground.
+3.0
EV
EV
AE
AE
H
126m
7.9m/s
1024.4m
1.6m/s
D
22
26
80
In Flight
P
H D
+0
33m 105m
0.8m/s 4.5m/s
10
10
1 2 3 4 5 6 7
121314
15
16
8
9
10
11

dji MAVIC MINI Specifications

General

Type	Quadcopter
Foldable	Yes
Product color	Black, White
Construction type	Ready-to-fly (RTF)
Maximum speed	13 m/s
Number of axis	3
Number of rotors	4 rotors
Maximum tilt angle	30 °
Maximum flight time	30 min
Maximum ascent speed	4 m/s
Maximum descent speed	3 m/s
Maximum flight altitude	3000 m
Maximum weight capacity	- kg
Maximum wind resistance	8 m/s
Horizontal hover accuracy	0.1 m
Number of propeller blades	2
Maximum pitch angular velocity	150 °/sec
Operating temperature (T-T)	0 - 40 °C
Megapixel	12 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 2720 x 1530 pixels
Maximum frame rate	60 fps
Optical sensor size	1/2.3 \
Camera shutter speed	4-1/8000 s
Supported video modes	1080p
Image formats supported	JPEG
Video formats supported	AVC, H.264, MP4, MPEG4
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	2720 x 1530 pixels
Field of view (FOV) angle	83 °
Bitrate at maximum video resolution	40 Mbit/s
Battery voltage	7.2 V
Battery capacity	2400 mAh
Transmitter battery capacity	2600 mAh
Maximum device width	160 mm
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
AC adapter power	18 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	1.5 A
AC adapter output voltage	12 V
Power consumption (transmitter) (max)	1200 mA
Cables included	Lightning, Micro-USB, RC, USB Type-C
Built-in processor	-

Weight and Dimensions

Depth	140 mm
Width	82 mm
Height	57 mm
Battery weight	100 g
Wheelbase diagonal	213 mm
Takeoff weight (max)	249 g
