Page #41 background imageLoading...
Page #41 background image
©
2019 DJI All Rights Reserved.
41
Aircraft
Takeo Weight
249 g / 199 g (JP version)
Dimensions (L×W×H) Folded: 140×82×57 mm
Unfolded: 160×202×55 mm
Unfolded (with propellers): 245×290×55 mm
Diagonal Distance
213 mm
Max Ascent Speed 4 m/s (S Mode)
2 m/s (P Mode)
1.5 m/s (C Mode)
Max Descent Speed 3 m/s (S Mode)
1.8 m/s (P Mode)
1 m/s (C Mode)
Max Speed (near sea level,
no wind)
13 m/s (S Mode)
8 m/s (P Mode)
4 m/s (C Mode)
Max Service Ceiling Above
Sea Level
3000 m
Max Flight Time 30 mins (measured while ying at 14 kph in windless conditions)
18 mins for JP version (measured while ying at 12 kph in windless
conditions)
Max Wind Speed Resistance
8 m/s (Scale 4)
Max Tilt Angle 30° (S Mode)
20° (P Mode)
20° (C Mode)
Max Angular Velocity 150°/s (S Mode)
130°/s (P Mode)
30°/s (C Mode)
Operating Temperature
Range
0° to 40° C (32° to 104° F)
GNSS
GPS+GLONASS
Operating Frequency Model MT1SS5: 5.725-5.850 GHz
Model MT1SD25: 2.400-2.4835 GHz, 5.725-5.850 GHz
Transmission Power (EIRP) Model MT1SS5
5.8 GHz: <30 dBm (FCC); <28 dBm (SRRC)
Model MT1SD25
2.4 GHz: <19 dBm (MIC/CE)
5.8 GHz: <14 dBm (CE)
Appendix
Specifications

Other manuals for dji MAVIC MINI

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the dji MAVIC MINI and is the answer not in the manual?

dji MAVIC MINI Specifications

General IconGeneral
TypeQuadcopter
FoldableYes
Product colorBlack, White
Construction typeReady-to-fly (RTF)
Maximum speed13 m/s
Number of axis3
Number of rotors4 rotors
Maximum tilt angle30 °
Maximum flight time30 min
Maximum ascent speed4 m/s
Maximum descent speed3 m/s
Maximum flight altitude3000 m
Maximum weight capacity- kg
Maximum wind resistance8 m/s
Horizontal hover accuracy0.1 m
Number of propeller blades2
Maximum pitch angular velocity150 °/sec
Operating temperature (T-T)0 - 40 °C
Megapixel12 MP
Sensor typeCMOS
Video resolutions1920 x 1080, 2720 x 1530 pixels
Maximum frame rate60 fps
Optical sensor size1/2.3 \
Camera shutter speed4-1/8000 s
Supported video modes1080p
Image formats supportedJPEG
Video formats supportedAVC, H.264, MP4, MPEG4
Maximum image resolution4000 x 3000 pixels
Maximum video resolution2720 x 1530 pixels
Field of view (FOV) angle83 °
Bitrate at maximum video resolution40 Mbit/s
Battery voltage7.2 V
Battery capacity2400 mAh
Transmitter battery capacity2600 mAh
Maximum device width160 mm
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size256 GB
Moving control functionsBackward, Downward, Forward, Turn left, Turn right, Upward
AC adapter power18 W
AC adapter frequency50 - 60 Hz
AC adapter input voltage100 - 240 V
AC adapter output current1.5 A
AC adapter output voltage12 V
Power consumption (transmitter) (max)1200 mA
Cables includedLightning, Micro-USB, RC, USB Type-C
Built-in processor-
Weight and Dimensions IconWeight and Dimensions
Depth140 mm
Width82 mm
Height57 mm
Battery weight100 g
Wheelbase diagonal213 mm
Takeoff weight (max)249 g
