dji MAVIC MINI User Manual

20
©
2019 DJI All Rights Reserved.
Mavic Mini User Manual
Using the Battery
Insert the battery in the battery compartment and secure the battery clamp. A clicking sound indicates
the battery is fully engaged. Make sure that the battery is fully inserted and the battery cover is secure in
place.
Checking Battery Level
Press the power button once to check the battery level.
Battery Level LEDs
: LED is on. : LED is ashing. : LED is o.
LED1 LED2 LED3 LED4
Battery Level
battery level
＞
88%
75%
＜
battery level
≤
88%
Refer to the Mavic Mini Disclaimer and Safety Guidelines before use. Users take full responsibility
for all operations and usage.
The Mavic Mini Intelligent Flight Battery cannot discharge automatically. If the battery will not
be used for more than 10 days, it is recommended to discharge the battery manually until the
battery level is between 39% and 75%.
Specifications of the Intelligent Flight Battery for the Japanese version are different. Refer to the
Specifications section for more information. The battery features are the same for all versions of
the Mavic Mini Intelligent Flight Battery.
DO NOT detach the battery when the aircraft is powering on.
Make sure that the battery is mounted firmly.
LED1
LED2
LED3
LED4
Battery Level LEDs
Power Button
Fully engagedNot engaged
Press the battery clamp and detach the battery from the battery compartment to remove it.
9. Communication: Information about the battery's voltage, capacity, and current is transmitted to the
aircraft.

dji MAVIC MINI Specifications

General

Type	Quadcopter
Foldable	Yes
Product color	Black, White
Construction type	Ready-to-fly (RTF)
Maximum speed	13 m/s
Number of axis	3
Number of rotors	4 rotors
Maximum tilt angle	30 °
Maximum flight time	30 min
Maximum ascent speed	4 m/s
Maximum descent speed	3 m/s
Maximum flight altitude	3000 m
Maximum weight capacity	- kg
Maximum wind resistance	8 m/s
Horizontal hover accuracy	0.1 m
Number of propeller blades	2
Maximum pitch angular velocity	150 °/sec
Operating temperature (T-T)	0 - 40 °C
Megapixel	12 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 2720 x 1530 pixels
Maximum frame rate	60 fps
Optical sensor size	1/2.3 \
Camera shutter speed	4-1/8000 s
Supported video modes	1080p
Image formats supported	JPEG
Video formats supported	AVC, H.264, MP4, MPEG4
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	2720 x 1530 pixels
Field of view (FOV) angle	83 °
Bitrate at maximum video resolution	40 Mbit/s
Battery voltage	7.2 V
Battery capacity	2400 mAh
Transmitter battery capacity	2600 mAh
Maximum device width	160 mm
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
AC adapter power	18 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	1.5 A
AC adapter output voltage	12 V
Power consumption (transmitter) (max)	1200 mA
Cables included	Lightning, Micro-USB, RC, USB Type-C
Built-in processor	-

Weight and Dimensions

Depth	140 mm
Width	82 mm
Height	57 mm
Battery weight	100 g
Wheelbase diagonal	213 mm
Takeoff weight (max)	249 g
