Aircraft

Phantom 3 Advanced

User Manual

The Battery Level Indicators will also show the current battery level during charging and

discharging. The indicators are dened below.

: LED is on. : LED is ashing.

: LED is off.

Battery Level

LED1 LED2 LED3 LED4 Battery Level

87.5%~100%

75%~87.5%

62.5%~75%

50%~62.5%

37.5%~50%

25%~37.5%

12.5%~25%

0%~12.5%

=0%

Battery life

Battery life refers to how many more times the battery can be discharged and recharged before it must

be replaced. When the battery is turned off, press and hold the Power Button for 5 seconds to check the

battery life. The Battery Level Indicators will light up and/or blink for two seconds, as shown below:

Battery Life

LED1 LED2 LED3 LED4 Battery Life

90%~100%

80%~90%

70%~80%

60%~70%

50%~60%

40%~50%

30%~40%

20%~30%

below 20%

When battery life reaches 0%, it can no longer be used.

For more information about the battery, launch the DJI Pilot app and check the information that is

listed under the battery tab.

Other manuals for dji Phantom 3 Advanced

Questions and Answers:

Need help?

Do you have a question about the dji Phantom 3 Advanced and is the answer not in the manual?

General

Maximum speed	16 m/s
Frequency band	2.4 - 2.483 GHz
Number of axis	3
GPS (satellite)	Yes
Number of rotors	4 rotors
Maximum flight time	23 min
Maximum ascent speed	5 m/s
Maximum descent speed	3 m/s
Maximum weight capacity	- kg
Maximum operating distance	5000 m
Megapixel	12.4 MP
Video resolutions	1280 x 720, 1920 x 1080, 2704 x 1520 pixels
Maximum frame rate	60 fps
Camera shutter speed	8 - 1/8000 s
Supported video modes	720p, 1080p, 1520p
Video formats supported	AVC, H.264, MOV, MP4, MPEG4
Live view frequency band	2.4 GHz
Maximum video resolution	2704 x 1520 pixels
Field of view (FOV) angle	94 °
Bitrate at maximum video resolution	40 Mbit/s
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	64 GB
Flight modes	Failsafe mode, Follow Me mode
Moving control functions	Backward, Downward, Flying sideways, Forward, Turn left, Turn right, Upward
Battery voltage	15.2 V
Battery capacity	4480 mAh
Transmitter battery capacity	6000 mAh
Number of batteries (transmitter)	1
Product color	White
Operating temperature (T-T)	0 - 40 °C
AC adapter power	57 W
AC adapter output voltage	17.4 V
Equivalent Isotropically Radiated Power (EIRP)	100 dBmW
Motor type	Brushless
