dji T50 - Maintenance; Specifications

12
©
2024 DJI All Rights Reserved.
Maintenance
1. Cleaning the spreader: After spreading, clean the residue in the spread tank and spreader
immediately. Make sure to dry the system afterwards.
2. Replacing the spinner disk: The spinner disk is a consumable part. Follow the steps below to
replace the spinner disk if there are obvious signs of wear.
a. Make sure that the aircraft is powered o.
b. Remove the pin, nut, washer, and spinner disk at the bottom of the spreader. Mount a
new spinner disk and secure it using the washer, nut, and pin.
Specications
Specications T50 Spreading System T25 Spreading System
Compatible Aircraft
[1]
Agras T50 Agras T25
Spreading System Weight
(inc. spread tank and
fenders)
6.0 kg 3.9 kg
Spread Tank Volume 75 L 35 L
Spread Tank Internal Load
[2]
50 kg 25 kg
Compatible Material
Diameter
0.5-5 mm
Spreading Range Varies according to the material diameter, spinner disk rotational
speed, hopper outlet size, and flight altitude. For optimal
performance, it is recommended to adjust the corresponding
variables to achieve a spreading range of 4.5-7 meters.
[1] The aircraft rmware must support the spreading system. Check the release notes of the corresponding
aircraft on the ocial DJI website.
[2] The DJI Agras app will intelligently recommend the payload weight limit for the spread tank according
to the current status and the surroundings of the aircraft. DO NOT exceed the recommended payload
weight limit when adding the material to the spread tank. Otherwise, ight safety may be aected.
• Refer to the Replacing Hopper Gate section to disassemble and clean the inside of the
spreader.
