Installation
• Make sure to remove the Intelligent Flight Battery from the aircraft before installation.
• Operate with caution to avoid injury caused by sharp or moving mechanical parts.
• Check the parts on the aircraft and spreading system after installation to make sure that
the spinner disk will not damage the cables or any other part during operation.
The T50 and T25 Spreading Systems are similar in appearance and operations. Unless otherwise
specied, the illustrations in this document use the T50 Spreading System as an example.
1. Locate the hoses on either side of the spray tank on the aircraft. Loosen the nut on the hose
and detach the hose and nut.
Note: After the hose is removed, make sure to tighten the hose nut on the spray tank hose
connector to avoid losing the nut.
2. Locate the spraying system cable on the rear left landing gear of the aircraft. Remove the
protective rubber casing on the cable and unplug the cable from the connector .
Operate with caution to avoid damaging the cable.
3. Lift and remove the spray tank from the aircraft.
1. 3.2.
