Operation Procedure
1. Power on the remote controller and then the aircraft. Enter Operation View in the DJI Agras
app.
2. Open the cover, add the compatible material, and close the cover. The DJI Agras app will
intelligently recommend the payload weight limit for the spread tank according to the
current status and surroundings of the aircraft. DO NOT exceed the recommended payload
weight limit when adding material to the tank. Otherwise, the ight safety may be aected.
3. Select the operation mode to Route mode. Plan a eld or select a eld in the eld list and
enter Edit mode to set the route parameters. Then tap Save to save the eld.
• Adjust the line spacing according to the ight altitude and spinner disk speed. It is
recommended to set the line spacing between 5 to 7 m. (within 6 m for materials,
such as rice seed)
4. Tap on the left side of the screen to select the operation field and tap Use to set the
spreading parameters. Select the required material and set the parameters as needed. The
adjustable parameters vary between dierent operation modes.
Route: Set the material amount, spinner disk speed, ight speed, and height relative to the
vegetation.
M+: Set the material amount, spinner disk speed, flight speed, line spacing, and height
relative to the vegetation.
M: There is no need to select the spreading materials. Set the hopper outlet size, spinner
disk speed, max. ight speed, and height relative to the vegetation. It is recommended to
follow the instructions below when spreading 45 kg/ha of materials:
• Adjust the hopper outlet size so that the spreading amount is 8 kg/min.
• Adjust the spinner disk speed so that the spreading range is 4.5-7 m.
• Maintain a ight speed of approximately 5-7 m/s.
5. Start the operation. The operations of the spreading system vary depending on the
operation mode.
Route Operation Mode
Route (Field) Operation: Tap Start after completing the spreading parameters. The aircraft
will then ascend to the preset takeo altitude and the spinner disk will start to rotate. When
the aircraft reaches the starting point of the route, the hopper gate opens and the aircraft ies
along the route and spreads material automatically. Spreading cannot be started or stopped
manually.
Route (A-B) Operation: Tap Start after completing the spreading settings. Switch to A-B
operation mode after the aircraft has reached the takeoff altitude and the spinner disk will
start to rotate. After Point A is recorded, the hopper gate opens automatically and will start
spreading when the aircraft flies from Point A to Point B. Spreading cannot be started or
stopped manually.
Using the operation resumption function: Once the operation is paused, the hopper gate
closes automatically to stop spreading, while the spinner disk continues to spin. After operation
is resumed, the aircraft returns to the breakpoint or projection point and continues spreading.
