18 | OPC506E(X) man.
STEP 4: TOW BAR ASSEMBLY & BATTERY
1. Tip the unit back and rest the feed chute on the ground.
2. Install the tow bar assembly with the 4 bolts provided.
3. Install the battery.
1
Connect the wiring as shown.
2
Secure the battery to the unit using 2 bolts and hardware
provided.
CAUTION: Be careful when connecting the battery
wires. DO NOT make contact with your tools or any other
conductive material to the metal frame when installing the
positive (red) wire.
ENGLISH
