v.220411 | 29
PARTS LIST
NO. SPECIFICATION NO. SPECIFICATION
1 Feed hopper 43 Washer Ø10 x Ø22 x 2.2
2 Outlet hopper 44 Rubber
3 Support foot 45 Bolt M8 x 70
4 Tow bar connecting part 46 Buckle
5 Wheel axle 47 Chain
6 Crush house 48 Bolt M10 x 90
7 Tool box cover 49 Tow bar
8 M8 lock nut 50 Trailer hitch
9 Lock washer Ø8 51 Square latch
10 Washer Ø8 x Ø16 x 1.6 52 Knob M12
11 Plate for protection sheet 53 Blade gap adjusting plate
12 Protection sheet 54 Feeding helper plate
13 Hexagon headed bolt M10 x 25 55 Engine wire
14 Key switch 56 Engine plate
15 Pipe plug 57 Key
16 Wire 58 Spacer sleeve Ø26 x Ø35 x 15
17 Belt 59 Engine
18 Spacer sleeve Ø8.5 x Ø14 x 40.7 60 Knob
19 Belt cover accessory plate 61 Outlet hopper adjusting plate
20 Bolt 5/16-24 - 2-1/4 62 Upper part of outlet hopper
21 Engine pulley 63 Bolt M6 x 16
22 Washer Ø10 x Ø44 x 5 64 Lock washer Ø6
23 Bolt 3/8-24UNF - 1-1/2 65 Clip
24 Belt cover 66 Bearing cap
25 Bolt M8 x 20 67 B shaft ring Ø30
26 Bolt M8 x 25 68 Pin Ø10
27 Washer Ø8.5 x Ø40 x 3 69 Pin Ø3 x 20
28 Rotor pulley 70 Bolt M4 x 16
29 Lock nut M10 71 Clip
30 Lock washer Ø10 72 Washer Ø4 x Ø9 x 1
31 Spacer sleeve Ø8.5 x Ø30 x 24.5 73 Lock washer Ø4
32 Key 74 Lock nut M4
33 Mounted bearings 75 Bolt M12 x 55
34 Steel plate for mounted bearing 76 Bolt M12 x 40
35 Rotor 77 Washer Ø13.5 x Ø24 x 2.5
36 Blade 78 Lock washer Ø12
37 Blade bolt 79 Lock nut M12
38 Hexagonal slotted thin nut M24 x 1.5 80 Battery rack
39 Washer Ø25 x Ø47 x 3 81 Cover plate
40 D.O.T. tire 82 Battery
41 Pin Ø4 x 40 83 Power cord
42 Bolt M10 x 80
