8860 Installation and Programming Guide | Digital Monitoring Products 5

PROGRAM THE PANEL

Before continuing with programming and setup, program the keypad in the panel as a device.

To access the Programmer menu, reset the panel by shorting the RESET header, press Keypad in the Carousel menu,

enter 6653 (PROG), then press CMD.

After completing each of the following steps, press CMD to advance to the next option. To exit the Programmer menu,

tap CMD to advance through the menu items until you reach the end of the menu. At the end of the menu, press the

back button twice to return to the main screen. Refer to the panel programming guide as needed.

Device Setup

Advance to Device Setup, then press a select area to enter the setup menu.

Device Number

Set the keypad address.

Panel Models Compatible Device Numbers

XR550 1 - 16

XR150 1 - 8

XT30/XT50 1 - 8

Device Name

Enter a name for the device.

Device Type

For use as a standard keypad, select KPD.

Communication Type

Ensure the COMM TYPE is set to KPD (Keypad Bus).

Conﬁgure additional options as needed.

DEVICE SETUP

DEVICE NO: -

DEVICE SETUP

*UNUSED*

DEVICE SETUP

TYPE: KEYPAD

DEVICE SETUP

COMM TYPE: KPD
