Instruction manual
Fire Alarm Panel FP9000A
DMTech LTD, 16 N.Haytov Street, Pleven Tel.: 0889992660 e-mail:office@dmtech-ltd.com page - 4 - of 20
ISO 9001:2015 Certified Company
• Voltage: 90 ~ 264 VAC
• Frequency: 50/60 Hz
Backup battery supply
• Charge voltage (U): 27.3V
• Storage battery: 2 x 12V / 5Ah, lead-acid, encapsulated
• Storage battery internal resistance Ri: < 0.3Ω
• Storage battery maximum dimensions: 2 pcs – 90х98х70mm
• Type of connection to battery: cable terminal
Load capacity
• Maximum load capacity of loop: 500 mA DC
• Maximum load capacity of AUX: 500 mA DC
• Maximum load capacity of outputs OUT1 and OUT2: 500 mA DC
• Maximum load capacity of outputs FIRE, FAULT and EXT: 300 mA DC
• Maximum total load (sum up of the 4 above): 2.0 A DC
• Programmable relay outputs: 1A@24VDC
List of fuses
• Main power supply: 4А, T-type, slow-melting, 5х20 mm
• Storage battery: 6.0А, T-type, slow-melting, 5х20 mm
•
Contents of delivery: Addressable Fire Alarm System FP9000A
1
Fire alarm panel FP 9000А
1 pc
2
Fuse 6,3А
1 pc
3
Fuse 4,0А
1 pc
4
Jumper for backup batteries
1 pc
5
Packing
1 pc
6
Resistor 4.7кΩ
3 pcs
WARNING!
The fire alarm panel must be installed by a qualified staff only.
Panel’s electronic components are vulnerable to electrostatic discharge.
DO NOT make any hardware changes in panel’s configuration while the panel is powered
by grid or backup batteries.
