DMTech FP9000A - Page 6

Instruction manual
Fire Alarm Panel FP9000A
DMTech LTD, 16 N.Haytov Street, Pleven Tel.: 0889992660 e-mail:office@dmtech-ltd.com page - 6 - of 20
ISO 9001:2015 Certified Company
Fig. 3 – Circuit board
components for
mounting:
а) View from the bottom;
b) Front view;
c) View from the top.
1 – Central mounting
holes
2 – Holes for pulling
cables through
3 – Holes for pulling main
supply cable through
4 – Additional holes for
cable pulling
2 2
170 mm
240 mm
1
3
5
a)
b)
c)
313 mm
218 mm
85 mm
Fuse 4A
N
L
Fuse 4A
to panel
Fuse 4A
~220V + 10%
50-60 Hz
No
EN54-2:1997/A1:2006/AC:2009
EN54-4:1997/A2:2006/AC:2009IP30
TYPE:FP9000A
Pb
U~(187 2 )V 50/60Hz; P=45VA 44 N
E Str. ,Pleven 1, А7 5800,xarch Joseph
Bulgaria, www.dm-teh.com
BG201673368
Made in EU
19221922-CPR-1267
Fire Alarm Panel
15
xxxx xxxx
