Cavity Cartridge Fuse Micro Fuse Description
* If Equipped
F101 – 15 Amp Blue In Car Temp Sensor / Humidity Sensor
F102 – 15 Amp Blue Spare
F103 – 10AmpRed PTC/RRHVAC*
F104 – 20 Amp Yellow PWR OUT-IP / Console / Trnk
BULB REPLACEMENT
Replacement Bulbs, Names, And Part Numbers
In the instance a bulb needs to be replaced, this section includes bulb description and replacement part numbers.
NOTE:
See an authorized dealer for LED bulb replacement.
Interior Bulbs
Bulb Name Bulb Number
Glove Compartment Lamp 194
Grab Handle Lamp L002825W5W
Overhead Console Reading Lamps VT4976
Visor Vanity Lamp V26377
Rear Cargo Lamp 214–2
Underpanel Courtesy Lamps 906
Instrument Cluster (General Illumination) 103
Telltale/Hazard Lamp 74
282 SERVICING AND MAINTENANCE
