Scaffold User Information Ringlock
Bracing Arrangements
4 Bay Long by 4 Bay Wide
For Birdcages 4x4 Bays and smaller, bracing is
required in both directions on 2 corners only. Bracing is
to be full height of the scaffold and decking is assumed
to be top lift only.
5 Bay Long by 5 Bay Wide
For Birdcages 5x5 Bays bracing is required in bothdi-
rections on all 4 corners. Bracing is to be full height of
the scaffold and decking is assumed to be top lift only.
Larger than 6 Bay Long by 6 Bay Wide
For Birdcages 6x6 Bays and larger, bracing is required
both directions no greater than 5 bays in any direction.
Bracing is to be full height of the scaffold and decking
is assumed to be top lift only.
Note:
For any alternate birdcage designs larger than 6 bays
wide by 6 bays long refer to your local Doka Technical
representative for further design and clarification.
