User Information Ringlock Scaffold
43999817902 - 10/2022
Raised Ledger System (RLS)
The Raised Ledger System is compatible with existing
Ringlock scaffolds and has been designed to provide
customers with a solution for creating seamless, safe
working platforms. The Raised Ledger system is ideal
for the following applications (but not limited to): Bird-
cages, Overhead Pavement Gantries, Suspended Plat-
forms, Industrial and Commercial Scaffolds, Stage and
Event scaffolds.
When scaffolding around protrusions use Mid Tran-
soms (Plank to Plank, Ledger to Plank and Ledger to
Ledger Transoms) to minimize the use of wood / timber
products on your job site.
▪ Raised Truss Ledger – is a load bearing horizontal
bearer (same as regular Ringlock Truss Ledgers).
Available lengths 1.57m to 3.07m.
▪ Raised Ledger – is a horizontal Ledger (runner) that
acts as a guardrail or can be used to support Rin-
glock Steel Planks. Available lengths 0.73m to
3.07m.
▪ Capping Piece – is used to close the gap between
two Raised Ledgers / Truss Ledgers by inserting into
the top of a Ringlock Standard (without spigot).
▪ Raised Ledger Guardrail – is a Ringlock ‘Crazy Leg’
or ‘Guardrail Standard’ but connects directly to the
Ringlock rosette and extends above the raised Plank
so that the guardrail can be installed at the correct
height.
▪ Raised Side Bracket – is similar in size and function
as the regular Ringlock Side Bracket but raises the
Planks by 200mm. The Side Brackets are available
in 1 to 3 plank widths.
