19
Technical Data
Shown: ET-70 C, 100 C
Power consumption Watt 700 1000
Mains power voltage V 230 230
Mains power frequency Hz 50 50
Rated current A 3,5 5
Mains fuse A 16 16
Power cable length cm 40 40
Extension cable (not included) type DIN 57282/H07 RN-F
max. length 30 meters, 3x1.5 mm
2
Radio Interference suppression/EMC per EMC guideline EWG 89/336 and 92/31
Protective insulation class II (double insulated)
Max. spindle speed
wiht 2-line trimmer head
1)
rpm 7.500 7.500
Sound power level LWA av per EN 786 Appendix E
2)
dB (A) 94,3 94
Sound pressure level LpA av at workplace EN 786 Appendix E
2)
dB (A) 81,9 85,3
Vibration acceleration ah,w per EN 786 Appendix D
2)
- front handle m/s
2
3,8 1,7
- rear handle m/s
2
4,1 2,2
Dimensions: length / width / height mm
1530 / 480 / 360
1530 / 480 / 360
Weight (with guard and cutting tool) kg 5,0 5,1
1) The maximum rated speed of the trimmer head is not exceeded when using a DOLMAR trimmer head.
2) Data based in equal parts on full load and top speed operation.
Type plate
Indicate when ordering spare parts!
Components
1 Cutting tool
2 Line knife
3 Guard (trimmer guard)
4 Shaft tube
5 Front handle
6 Rear handle with grip safety
7 Powerplug
8 Cable detensioner
9 Ventilation slot
10 ON/OFF switch
11 Mounting plate
12 Handguard
13 Rest
14 Type plate
Serial number
Year of manufacture
1
2
3
4
5
6
7
8
9
10
11
12
13
ET-70 C ET-100 C
14
