10
To meet the applicable safety provisions, only the tool/ protector combinations as
indicated in the table must be used.
Be sure to use genuine DOLMAR cutter blades or nylon cutting head.
– The cutter blade must be well polished, free of cracks or breakage. If the cutter blade hits
against a stone during operation, stop the engine and check the blade immediately.
– Polish or replace the cutter blade every three hours of operation.
– If the nylon cutting head hits against a stone during operation, stop the engine and check the
nylon cutting head immediately.
MOUNTING OF PROTECTOR
– Fix the protector (1) to the clamp (3) with two bolts M6 x 30 (2).
– When using the string head, fit the protector (6) into the protector (1), and
tighten them with two nuts (5) and two screws (4).
Star Blade
Eddy Blade
Protector for metal blades
Nylon cutting head
Protector for cord cutter
