26
6-12. Stopping the engine
Depress the combination switch (1).
NOTE: After being pressed down, the combination switch will
revert to the ON position again. The engine is switched o, but
can be turned on again without moving the combination switch.
IMPORTANT: To cut o the ignition current, push the
combination switch all the way down past the resistance point
to the safety position (
).
6-13. Checking the chain brake
The chain brake must be checked before every use of the
saw!
Start the engine as described above (have a secure footing,
place the chain saw on the ground so that the chain and guide
bar are not near anything).
(Fig. 57)
Hold the front handle rmly, with your other hand on the rear
grip.
Let the engine run at medium speed and push the handguard
(6) in the direction of the arrow using the back of your hand,
until the chain brake engages. The chain should now stop
immediately.
Bring the engine back to idle and release the chain brake.
Caution: If the chain does not stop immediately in
the chain saw in this condition! Contact a DOLMAR
authorized service center.
6-14. Adjusting the carburetor
(Fig. 58)
CAUTION: Carburetor adjustment may only be done by a
specialist DOLMAR service center!
SERVICE
Only adjusting screw (S) can be manipulated by the user.
If the saw chain moves in idle (i.e. without the throttle being
pressed), it is imperative to correct the idle speed!
Do not adjust the idle speed until after complete
assembly and testing of the saw!
Idle speed adjustment must only be undertaken when
installed guide bar and chain.
Use a screwdriver (4 mm blade) for idle adjustments.
Adjusting the idle speed
Turn adjusting screw (S) counter-clockwise (unscrew): Idle
speed decreases.
Turn adjusting screw (S) clockwise (screw in): Idle speed
increases.
Important: If the saw chain still moves during idle even
after you have adjusted the idle speed, do NOT use the
saw. Take it to a DOLMAR service center!
