Dolmar PS-32PS-32 - Spare Parts List Extract

33
10. Extract from the spare parts list (Fig. 76)
Use only original DOLMAR parts. For repairs and
replacement of other parts, see your DOLMAR service center.
PS-32
Spare parts
Pos. Qty. Denomination
1 1 Sprocket nose bar 3/8”, 30 cm, 1.3 mm (12”)
1 Sprocket nose bar 3/8”, 35 cm, 1.3 mm (14”)
1 Sprocket nose bar 3/8”, 40 cm, 1.3 mm (16”)
2 1 Saw chain 3/8” for 30 cm, 1.3 mm
1 Saw chain 3/8” for 35 cm, 1.3 mm
1 Saw chain 3/8” for 40 cm, 1.3 mm
1 1 Sprocket nose bar 3/8”, 30 cm, 1.1 mm (12”)
1 Sprocket nose bar 3/8”, 35 cm, 1.1 mm (14”)
2 1 Saw chain 3/8” for 30 cm, 1.1 mm
1 Saw chain 3/8” for 35 cm, 1.1 mm
1 1 Sprocket nose bar 3/8”, 30 cm, 1.3 mm (12”)
1 Sprocket nose bar 3/8”, 35 cm, 1.3 mm (14”)
1 Sprocket nose bar 3/8”, 40 cm, 1.3 mm (16”)
2 1 Saw chain 3/8” for 30 cm, 1.3 mm
1 Saw chain 3/8” for 35 cm, 1.3 mm
1 Saw chain 3/8” for 40 cm, 1.3 mm
1 1 Sprocket nose bar 3/8”, 30 cm, 1.1 mm (12”)
1 Sprocket nose bar 3/8”, 35 cm, 1.1 mm (14”)
2 1 Saw chain 3/8” for 30 cm, 1.1 mm
1 Saw chain 3/8” for 35 cm, 1.1 mm
3 1 Chain protector for 30-35 cm (3/8”)
1 Chain protector for 40 cm (3/8”)
4 1 Universal wrench SW 16/13
6 1 Carburetor screwdriver
7 1 Suction head
8 1 Fuel tank cap, cpl.
9 1 O-Ring 29.3 x 3.6 mm
10 1 Return spring pack, complete
11 1 Spring
12 1 Driver
13 1 Starter cable 3.0 x 900 mm
14 1 Spark plug
15 1 Oil tank cap, cpl.
16 1 O-Ring 29.3 x 3.6 mm
17 1 Air lter
18 1 Sprocket guard, cpl.
1 Sprocket guard (with fast tensioner), complete
19 2 Hexagonal nut M8
20 1 Clutch drum cpl. 3/8”, 6-tooth
21 1 Shim washer
22 1 Circlip
23 1 Spark arrester screen
Accessories (not delivered with the chain saw)
25 1 Chain gauge
26 1 File handle
27 1 Round le, dia. 4.5 mm
28 1 Round le, dia. 4.0 mm
29 1 Flat le
30 1 File holder (with round le dia. 4.5 mm)
31 1 File holder (with round le dia. 4.0 mm)
32 1 Oset screwdriver
- 1 Combined can
(for 5l fuel, 3l chain oil)
