User Manual of DOLCWIUHFP
10
3. The data wire should be with shielding layer and should be connected with the GND to
avoid any interference.
4. Adjust the reader range to make sure the tag can be detected when the vehicle with the tag
is approaching ticket box and within one lane area only, so that there is only one vehicle and one
tag in the operation area to avoid any wrong operation.
1 Tag Installation
3.1 Overview
WINGSAFE provides 3 types of tag according to different demands:
Type Photo Suitable Way
Card
1. Fixed with card holder
2. Handheld by user
Sticker 1. Stick on the surface of the glass
Metal Tag 1. Fixed on the surface of the metal
3.2 Instruction
3.2.1 Card
3.2.1.1 Fixed with card holder
Transmitter Solutions provides 2 types of card holder according to different demands:
Type Photo Suitable Way
Fixed Holder
Fixed on the windows, see the
remark
Rotatable
Holder
Fixed on the driver platform
