User Manual of DOLCWIUHFP
3
1.1.3 Parameters
The parameters of Transmitter Solutions DOLCWIUHFP Table 1.1.3-1
Table 1.1.3-1
1.2 System Description
1.2.1 Components
The package of contents the components list in the
Table 1.2.1-1.
Table1.2.1-1
No
Component Specification Quantity Remark
1
Host 370* 360 * 96 mm 1 PC With Fixed Holder
2
RS232 Cable 1 PC
3
Test Tag 86 * 54 * 1.0 mm 1 PC Optional
4
Definition of Connection Pins 1 PC
5
Packing List 1 PC
No
Parameter Value
1
Operating Frequency 902 928 MHz FHSS
2
Transmitter Power 0.5 to 2W (programmed by software)
3
Supply Voltage 10~25 VDC +5%/-1%, Ripple: maximum 50 mV
4
Communication Rates 9600 bps
5
Power Consumption Maximum 10 W
6
Interfaces Optional Wigand 34, RS232, RS485
7
Overall Size 370* 360 * 96 mm
8
Package Size 430 * 420 * 190 mm
9
Net Weight: 3.0 KGS
10
Operating Temperature -20°C to +70°C
11
Storage Temperature -40°C to +90°C
Transmitter Solutions DOLCWIUHFP
