The DIP switches on the units have the following functions:
DIP switches
Switch
Position
Function
1
ON
RS485 terminating resistor activated
OFF
RS485 terminating resistor deactivated
2
ON
RS485 mode activated; RS232 mode deactivated
OFF
RS485 mode deactivated; RS232 mode activated
3
ON
Service mode
OFF
Normal mode
4
ON
Status LEDs activated
OFF
Status LEDs deactivated
Caution! Ensure a suitable voltage supply and note the positions of the
DIP switches.
