DOM ENiQ AccessManager - Page 51

ENiQ® Wall Readers & Terminals
_____________________________________________________________________________________
51
ENiQ AccessManager® HiSec or
ENiQ AccessManager® Terminal
HiSec with one reader:
The upper LED is lit red.
Please note! If the upper LED
does not light up, check the
voltage supply connection.
Status LED with one reader
ENiQ AccessManager® HiSec with
two readers:
The upper LED is lit orange.
Status LEDs for two readers
Please note! If the upper LED
does not light up, check both
readers. If the upper LED is lit
green,
check reader 1. If the upper
LED is lit red, check reader 2.
ENiQ AccessManager® HiSec with
three readers:
The upper LED is lit orange.
The lower LED is lit green.
Status LEDs for three readers
Please note! If none of the
LEDs are lit, check all the
readers. If the upper LED is lit
green, check reader 1. If the
upper LED is lit red, check
reader 2.
