Dometic D21 - Clearing the Oven Flue (Vent)

23
EN
Range Service Procedures
RA/RV models only
q
w
12 Clearing and Cleaning the Orifice
q
Screw
w
Burner Assembly
1. Perform the steps in Accessing the Range
Components for RA/RV Models (on page 19)
before proceeding with service.
I
For RA Models, the burner will twist off when you
remove the cooktop.
2. Loosen the screw holding the burner assembly to the
burner box.
3. Gently pull the burner assembly back.
4. Remove any blockages using a toothpick.
5. Wipe the orifice with alcohol using a cotton swab.
6. Test the burner operation aer the alcohol has dried
and any fumes have dissipated.
7.9 Clearing the Oven Flue (Vent)
13 Clearing the Oven Flue (Vent)
1. Open the oven door.
2. Locate the oven flue (vent). See Component
Locations (on page 8) for more detail.
3. Carefully remove the obstruction using fingers or
pliers.
