General Information Range
RA34/RA35 Models
RA 21 3 2 - B S E
Ignition Type
Door Color
Cooktop Color
Revision Number
Number of Burners
Oven Size
Type of Appliance
Type of Appliance RA = range, Atwood
Oven Size
• 17 = 17 in. (432 mm)
• 21 = 21 in. (534 mm)
Number of Burners
3 (sealed)
Revision Number
• 0
• 1
• 2
• 3
Cooktop Color
• B = black
• W = white
Door Color
• B = black
• S = stainless steel
• 2 = white glass
Ignition Type
• P = Piezo
• E = electronic
RV34/RV35 Models
RV17 3 1 B B P X N R UPS
Shipping
Packaging
Control Panel
Tubing
Ignition Type
Door Color
Cooktop Color
Revision Number
Number of Burners
Oven Size
Type of Appliance
Type of Appliance RV = range, Vision
Oven Size
• 17 = 17 in. (432 mm)
• 21 = 21 in. (534 mm)
Number of Burners
3 (open-well)
Revision Number
• 1 = original version
• 2 = effective 8/1/01
• 3 = white panel/white
handle
Cooktop Color
• B = black
• W = white
• Q = bisque
• S = stainless steel
Door Color
• B = black
• G = black glass
• S = stainless steel
• 1 = white
• 2 = white glass
• 3 = white panel/handle
• 4 = stainless panel/
white handle
Ignition Type
• P = Piezo
• E = electronic
Tubing
X = extended gas tube
Control Panel
N = flush control panel
Packaging
R = returnable package
Shipping
UPS = shippable by UPS
S31 Models
S 3 1 B P F M O
Shipping
Trim Color
Grate Type
Ignition Type
Cooktop Color
Series Number
Number of Burners
Type of Appliance
Type of Appliance S = slide-in
Number of Burners
3
Series Number
1
Cooktop Color
• B = black
• S = stainless steel
Ignition Type
• M = match light
• P = Piezo
Grate Type
• F = flat wire
• C = cast
Trim Color
• B = black
• M = silver (metalized)
Shipping
• O = OEM single pack
• U = shippable by UPS
4.3 Component Locations
Figure 1 and shows the general component locations for
the ranges. Actual model component locations may vary.
