DIAGRAMS Eskimo Ice Installation & Operation Manual
24 L-3040 ENGLISH
Figure 13: Diagram of System Components and Water Flow
Figure 14: EI540D Connection Locations
Seawater Out
Fresh Water In
Ice Outlet
Electrical Box Wire
Seawater In
Drain
