Installation Rooop Air Conditioner (Air Distribution Box, Wall Thermostat Controls)
Roof thickness 1.25 to 5.5 in. (32 to 140 mm)
All models
1
Roof
thickness
1.25in.
(32 mm)
1.5 in.
(38 mm)
2.0in.
(51mm)
2.5in.
(64mm)
3.0in.
(76 mm)
3.5 in.
(90 mm)
4.0in.
(102 mm)
4.5in.
(114mm)
5.0in.
(127 mm)
5.5in.
(140 mm)
Total divider
thickness
1.7in.
(50 mm)
2.4in.
(60 mm)
2.8in.
(70 mm)
3.5 in.
(90 mm)
3.9 in.
(100 mm)
4.3in.
(110 mm)
4.7in.
(120 mm)
5.5in.
(140 mm)
5.9in.
(150 mm)
6.3in.
(160 mm)
Top foam
0.4 in.
(10 mm)
x x x x x x x x x x
Top foam
ring
0.4 in.
(10 mm)
x x x x x x x x x x
Foam
divider
0.4 in.
(10 mm)
x x x x x x x
Foam
divider
0.4 in.
(10 mm)
x x x
Foam
Divider
1.2 in.
(30 mm)
x x x x x x x
Foam
divider
1.2 in.
(30 mm)
x x x x x
Foam
divider
1.2 in.
(30 mm)
x x x
ADB adaptor
1.2 in.
(30 mm)
x x x x x x x x x x
1
Up to 0.4 in. (10 mm) of compression of the foam dividers is acceptable and may be required in some instances.
