ITA-GB- D00 - 2020
COMBO DRIVE FOR UPC SERIES
49
ALLARME
ALARM CODE
INCONVENIENTE
FAULT
POSSIBILI CAUSE
POSSIBLE CAUSES
RIMEDI
SOLUTIONS
EFFETTO
circuito 1/2/3/4
Allarme inviluppo zona : 1-
>9
Il compressore sta lavorando in una
zona di inviluppo non ottimale.
Zona n°.
2:Alto rapporto di
compressione.
3:Superato il limite di alta
pressione di condensazione.
4:Superato il limite di corrente
al motore.
5:Superato il limite alta
pressione evaporazione.
6:Basso rapporto di compr.
7:Basso rapporto di press.
8:Bassa pressione di cond.
9:Bassa pressione evaporaz.
Il Sistema tramite l’inverter
e l’EVD cerca di riportare il
compressore nella zona di
inviluppo ottimale.
Se il problema persiste
contattare l’assistenza.
Solo segnalazione.
circuit 1/2/3/4
Envelope alarm
The compressor works in a non-
optimal envelope zone.
Zone n°.
2:High compression ratio.
3:High condesation pressure
4:Exceeded max motor
current.
5:High evaporation pressure
6:Low compression ratio.
7:Low pressure difference.
8:Low condens.pressure.
9:Low evaporate.pressure.
The system through the
inverter and the EVD, tries
to brong the compressor
into the optimal envelope
area.
If the problem persist
contact support.
Just warning signal.
circuito 1/2/3/4
Basso differenziale di
pressione.
La differenza tra la pressione di alta e
la pressione di bassa è inferior al
limite prestabilito.
Lubrificazione compressore
insufficiente.
Stop compressore
Circuit 1/2/3/4
Low pressure differential.
The difference between high pressure
and low pressure is under threshold
setting.
Insufficient compressor
lubrification.
Stop compressor.
circuito 1/2/3/4
Alta temperature gas di
scarico
La temperatura dei gas di scarico ha
superato la soglia impostata.
Stop compressore
circuit 1/2/3/4
High discharge gas
temperature
Discharge gas temperature io over
threshold setting.
Stop compressor.
Sensore temp. B1 circuito 1
rotto o non collegato
Il sensore di temperature ripresa
potrebbe essere rotto o non
collegato.
Stop compressore.
Probe sensor B1 circuit 1
broken or not connected
Return probe sensor could broken or
not connected.
Stop compressor.
Sensore temp.B2 circuito 1
rotto o non collegato
Il sensore di temperatura mandata
potrebbe essere rotto o non
collegato.
Stop compressore.
Probe sensor B2 circuit 1
broken or not connected
Supply probe sensor could broken or
not connected.
Stop compressor.
Sensore temp. B3 circuito
1/2/3/4 rotto o non
collegato
Il sensore di bassa temperatura
circuito frigo potrebbe essere rotto o
non collegato.
Stop compressore.
Probe sensor B3 circuit
1/2/3/4 broken or not
connected
The low temperature refrigerator
sensor could be broken or not
connected.
Stop compressor.
Sensore temp.B4 circuito
1/2/3/4 rotto o non
collegato
Il sensore di alta temperatura circuito
frigo potrebbe essere rotto o non
collegato.
Controllare le connessioni Stop compressore.
Probe sensor B4 circuit
1/2/3/4 broken or not
connected
The high temperature refrigerator
sensor could be broken or not
connected.
Check connection. Stop compressor.
Sensore temp.B4 circuito
1/2/3/4 rotto o non
collegato
Il sensore di alta temperatura circuito
frigo potrebbe essere rotto o non
collegato.
Controllare le connessioni Stop compressore.
Probe sensor B4 circuit
1/2/3/4 broken or not
connected
The high temperature refrigerator
sensor could be broken or not
connected.
Check connection. Stop compressor.
