Table 9: Connection diagram SC480
No. Description
1 Solar charge controller
2 TD283 touch display (accessory)
3 Temperature sensor
4 WAGO connector
5 Solar panel(s)
House battery
Starting battery (optional)
Table 10: Color coding
Code Colour
rd red
bk black
18
