SL
Tabela 195: Barvne kode
Koda Barva
rd Rdeča
bk Črna
Različica priključitve D (velja samo za SC480)
Pri priključitvi solarnega polnilnika upoštevajte prikaz na sl. na strani399.
Tabela 196: Priključni načrt za SC480
Št. Opis
1 Solarni regulator polnjenja
2 Zaslon na dotik TD283 (dodatna oprema)
3 Senzor temperature
4 Priključek WAGO
5 Solarna plošča oz. plošče
399
