Dometic SeaStation - Mounting Options; Sensor Dimensions

2-4
EN
Figure 2-2. Sensor dimensions without mounting hardware.
2.4.1
2.4.2
2.4 Mounting options
Mounting options
This section provides information on determining the best location for the
SeaStation sensor.
The SeaStation kit that is purchased determines the mounting style; either
surface mount or pole mount. The sensor allows for both pole or surface
mounting. Follow directions below for detailed mounting directions.
SeaStation sensor dimensions
Figure 2-2 illustrates the physical dimensions of the sensor.
13.71"
6.23"
3.70 "
2.50"
2.93"
0.37"
5-PINS CONNECTOR
4X M8X 1.25 0.50"
NOTE
Dometic recommends a mounting kit is utilized. Surface mounting
hardware is not provided with the mounting kits shown.
