Dometic SeaStation - Mounting Templates; Low Profile Mount Template; High Profile Mount Template

3-9
EN
4X Ø .35" MAX
MOUNT BASE
PERIMETER
3.7"
2.5"
Figure 3-6. High profile mounting template.
3.7.2 High profile mount
NOTICE!
If this template has been downloaded electronically or copied from
another document, please verify all template dimensions prior to cutting.
Print/copy reproductions may be scaled differently.
✁
