2.7 Commissioning
Tuning
The key to good SeaStation performance is a well tuned joystick.
SeaStation usually operates at low RPMs so emphasis needs to be put on
tuning the joystick at its “Off-Idle” position. There are three steps:
1. Balance rotation power Off-Idle REV/FWD Ratio.
2. Tune Off-Idle Rudder Angle.
3. Balance sideways power Off-Idle REV/FWD Ratio.
NOTICE!
These steps are optional in Book 65 (Joystick tuning section) but are
required for all SeaStation systems, and must be re-tuned when upgrading
an existing Optimus 360 system from Rev J CANtrak soware (Spring
2016) or earlier.
NOTICE!
The Normal and Boost tuning values seen right and on the following
pages do not need to be re-tuned – only the Off-Idle values.
STEP 1
1. Bring the boat to a stop with boost mode off.
2. Navigate to Dealer Menu > Initial Setup > Joystick > Balance
Rotation Power.
3. Select Off-Idle REV/FWD Ratio.
