Dometic VARC 72 - Program Configuration Menu

28
Program
Program
Setpoints
Clock/Scheduler
Input/Output
Alarm History
Board Switch
Technician
Factory
Analog Output
Output #.# Vdc
Setpoints
Heating Temperature #.# °F
Cooling Temperature #.# °F
Electric Heat*
SP #°F
1-Stage Up #°F
1-Stage Down #°F
Current Limiting
Mode Normal/Boost/Econo
Econo 4.0 Amps
Normal 10.0 Amps
SW Pump Control By Demand/By Unit On
Startup Mode* Normal/Accel
Multistage Ramping all run at 50 rps when a
new compressor is turned on* Yes/No
Temperature Units °F/°C
Pressure Units psi/bar
Clock/Scheduler
Date ##/##/##
Hour ##:##
Day #
DST Enable/Disable
DST Enable
Transition Time #
Start #
End #
Input/Output
Analog Input
Digital Input
Relay Output
Analog Outputs
Analog Input
CW Return Input B001 #
CW Supply Input B002 #
SW Inlet Input B003 #
Digital Input
Flow switch DI 3 Open/Close
Electric Heat Flow Switch DI 5 Open/Close
High pressure switch DI 1 Open/Close
Load Shedding Switch DI 4 Open/Close
Relay Output
SW Pump Relay 1 On/Off
CW Pump Relay 2 On/Off
REV Valve Relay 3 On/Off
Alarm Relay 7 On/Off
Board Switch
Unit address: #
Switch to unit: #
Factory
See page 31
Technician
See page 29
Alarm History
Alarm# Alarm
Message
Compressor Speed #
CW Return #
CW Supply #
Discharge Pressure
#
