Program/Technician
BMS Configuration
BMS Port No. #
Protocol ###### (scroll to
select)
Address #
Baud Rate #####
Technician
Information
Commission
Working Hours
BMS Configuration
Service Settings
Manual Management
Pump Control
Information
Service Contact Phone ###-###-####
Commission Date ##:##
##/##/##
VARC type #
Version & Date #.# ##/##/##
BIOS & Date #.# ##/##/##
Boot & Date #.# ##/##/##
Flash Ram # Kb
T memory #
## Cycle/s # ms
Power Cycle Status
Last Off Time ##/##/## ##:##:##
Last On Time ##/##/## ##:##:##
Length Time off Days: # Hrs: ## Min:
##
EVO no.
FW Version #.#
Service Version #.#
Power+ no.1
Boot release #
FW release #
FW checksum #
MC release #
Hardware ID #
Commission
Enter contact info
Name ####
Telephone No. ###-###-####
Update info? Yes/No
Commission date ##:## ##/##/##
Commission system? Yes/No
Working Hours
Run Hours Number Starts
Compressor # h #
Chilled Water Pump # h #
Seawater Pump # h #
Service Settings
See page 30
Manual Management
Analog Input
Digital Input
Relay Output
Compressor & EEV
Analog Input
Manual Control Manual Pos. Status Value
CW Return B001 On/Off #.# #.#
CW Supply B002 On/Off #.# #.#
SW Inlet B003 On/Off #.# #.#
Digital Input
Manual Control Manual Pos. Status Value
Flow DI 3 On/Off Open/Close Open/Close
El. Heat Flow DI 5 On/Off Open/Close Open/Close
High pressure DI 1 On/Off Open/Close Open/Close
Load shedding DI 4 On/Off Open/Close Open/Close
Relay Output
Manual Control Manual Pos. Status Value
SW Pump Relay 1 On/Off On/Off On/Off
CW Pump Relay 2 On/Off On/Off On/Off
Rev valve Relay 3 On/Off On/Off On/Off
Alarm Relay 7 On/Off On/Off On/Off
Compressor & EEV
Enable manual valve position
Yes/No
Manual Valve position # steps
Compressor
Mode Auto/Manual
Manual Speed #.# rps
Required cap. #.# %
Actual cap. #.# %
Actual Speed #.# rps
Pump Control
CW Pump
Manual Enable On/Off
Manual Position On/Off
Action Status On/Off
