Appendix VI Default Parameters
Parameter
VARC 48
VARC 60
VARC 72
Data Type
Cooling Setpoint CCW
Return
48
48
48
Deg F
Cooling Setpoint CCW
Supply
42
42
42
Deg F
Heating Setpoint
110
110
110
Deg F
Panasonic Compressor
5KD184XAB21
5JD420XAA22
5JD420XAA22
Inverter part number
PSD1* 12 amp
PSD1* 12
amp
PSD1* 16
Amp
Current Limit Setpoint
According to Drive limit
12 Amps
12 Amps
16 Amps
Econo Mode
4
6
6
Amps
Normal Mode
10
10
12
Amps
Superheat Setpoint
Cool and Heat
10
10
10
Deg F
Factory Settings
Control Temp mode
CCW Return
CCW Return
CCW Return
Number of Stages
1
1
1
Electric Heat
No
No
No
Pwr Cycle
Retain Mode
Retain Mode
Retain Mode
Electric Heat
No
No
No
Logo
Dometic BLK
Dometic BLK
Dometic BLK
Background
Ocean
Ocean
Ocean
Flow Switch
Yes
Yes
Yes
High Pressure Switch
Yes
Yes
Yes
\ow Pressure Switch
No
No
No
Load Shedding
Yes
Yes
Yes
Condenser Monitoring
Yes
Yes
Yes
Load Shedding
Yes
Yes
Yes
SW Pump Settings
Control
By Demand
By Demand
By Demand
Off Delay
5
5
5
Seconds
CW Pump Settings
Control
Continuous
Continuous
Continuous
Flow Prove Delay
10
10
10
Seconds
Off Delay
5
5
5
Seconds
Reversing Valve
RV Delay Time before
Toggle Cool Mode
90
90
90
Seconds
RV Toggle Time
2
2
2
Seconds
RV Toggle Time
2
2
2
Seconds
Compressor
Min On Time
60
60
60
Seconds
Min Off Time
180
180
180
Seconds
Compressor
Min Time between Starts
180
180
180
Seconds
Load Up Time
10
10
10
Parameter
VARC 48
VARC 60
VARC 72
Data Type
Compressor Frost Protection
