Domino Ax350i User Manual

OPERATION
EPT019297 Issue 1 November 2016 4-33
(10) Select the Save icon to save the change.
End of procedure.
Invert Flip the barcode upside down.
Reverse Reverse the barcode.
Rotation Rotate the barcode by 0° 90° 180° or 270°.
Check digit algorithm If required, select a check digit algorithm.
Default setting: None
Quite zone: Left Add an empty area to the left of the barcode.
Quite zone: Right Add an empty area to the right of the barcode.
Setting Name Explanation

Domino Ax350i Specifications

General

Print Technology	Continuous Inkjet (CIJ)
Printhead	i-Pulse Printhead
Ink Type	MEK, Acetone, Ethanol based inks
User Interface	Touchscreen
Connectivity	Ethernet, USB
Operating Temperature	5°C to 45°C
Resolution	300 dpi
Maximum Print Width	4.09 inches
