Domino Ax350i User Manual

SYSTEM DESCRIPTION
EPT019297 Issue 1 November 2016 2-9
External Connections
Ink System
Interface communication: 1 x non standard DVI connection providing 24V DC, 500 mA
Product Detect / Shaft
Encoder Connector:
8-Way Socket
Power connector: 3-Way Plug, cable supplied
Hardware Pack Options:
Extended Comms Pack:
(P/N EPT022070)
Powered HMI Port
USB Port
Extended IO Pack:
(P/N EPT022071)
User Port: 25-Way D-Sub Socket
User Port: 37-Way D-Sub Socket
Status Pack:
(P/N EPT022072)
Beacon Connector: 5-Way Socket
Alarm Connector: 7-Way Socket, 1A, 30V maximum
RS232 Pack:
(P/N EPT022073)
Serial (RS232) Port: 8-Way Socket
GPIO Pack:
(P/N EPT022074)
Basic GPIO Port
Comms Pack:
(P/N EPT022075)
Ethernet Port
USB Port
ITM Type 2 Capacity: 1222ml maximum
ITM Type 3 (for heavy duty
ink system) Capacity:
1118ml maximum
Make-up Module
Capacity:
888ml maximum
Ink Cartridge Capacity: 825ml
Ink Cartridge (for heavy
duty ink system) Capacity:
555ml
Make-up Cartridge
Capacity:
1200ml
Ink Viscosity Control: Automatic Viscometer
Ink Bleed Control: Automatic Start-Up/Shut-Down

Domino Ax350i Specifications

General

Print Technology	Continuous Inkjet (CIJ)
Printhead	i-Pulse Printhead
Ink Type	MEK, Acetone, Ethanol based inks
User Interface	Touchscreen
Connectivity	Ethernet, USB
Operating Temperature	5°C to 45°C
Resolution	300 dpi
Maximum Print Width	4.09 inches
