Domino Ax350i User Manual

OPERATION
4-56 EPT019297 Issue 1 November 2016
EDITOR DEFAULTS
Set the default label settings. New labels will use these defaults.
Print Offset
Home > Setup> Editor Defaults > Properties
The Forward offset is used to adjust the position of the label on the print surface. If the print head
is on a traversing line the Reverse offset can also be set.
Note: This is a global print setting, label designs can also be saved with their own individual
print offset, see page 4-22.
Print Offset Diagram
Print Delay Print Delay
Reverse
Offset
Forward
Offset
Direction of printDirection of print
Print
Trigger
Print
Trigger

Domino Ax350i Specifications

General

Print Technology	Continuous Inkjet (CIJ)
Printhead	i-Pulse Printhead
Ink Type	MEK, Acetone, Ethanol based inks
User Interface	Touchscreen
Connectivity	Ethernet, USB
Operating Temperature	5°C to 45°C
Resolution	300 dpi
Maximum Print Width	4.09 inches
