Domino Ax350i User Manual

INSTALLATION
EPT019297 Issue 1 November 2016 3-17
(19) Enter the following information:
(20) Select the green Tick icon.
(21) Details of the printer will now appear on the screen.
(22) Select the Network icon in the bottom left corner of the PC’s QuickStep programme.
(23) Select the Connect to connect to a printer.
End of procedure.
Setting Name Explanation
Name Enter the name of the printer.
Type Select the type of printer which the QuickStep emulator is
connecting to. In this case, select CIJ.
IP address Enter the IP address of the printer.
Host Enter the host name.

Domino Ax350i Specifications

General

Print Technology	Continuous Inkjet (CIJ)
Printhead	i-Pulse Printhead
Ink Type	MEK, Acetone, Ethanol based inks
User Interface	Touchscreen
Connectivity	Ethernet, USB
Operating Temperature	5°C to 45°C
Resolution	300 dpi
Maximum Print Width	4.09 inches
