INSTALLATION
40 77091 Issue 2 November 2003
(6) Carefully reassemble the base unit and tighten all the screws. Complete the
installation process before switching on the machine.
Note: The voltage setting on the serial number label must be changed to correspond to the
PSU setting.
Jumpers
Fuse
Location of Jumpers and Fuse in
Three Litre Base
240V
220V
110V
0.25A
0.25A
0.5A
Three Litre Base Link Settings and Fuse Ratings
