BASIC OPERATIONS
77144 Issue 8 August 2009 37
RELEASING THE AIR FLOW VENT
WARNING: If the printer is being run for the first time since
installation or re-mounting, the air flow vents must
be released.
There are two air flow vents in the C6000 and C6000(i), and one in the C3000
and C1000 that require releasing prior to initial power up. There is also a vent in a
2L base that needs to be released.
For the vent(s) on the header tank:
(1) Using a screwdriver, remove the four screws
securing the control unit cover.
(2) Carefully raise the control unit cover and move back
just enough to expose the header tank in the top left
corner of the control unit.
(3) The header tank air flow vent is a small plastic
valve located on the top of the header tank.
Air Flow
Vent
Air Flow
Release
Locking
Screw
To Next Page
