BASIC OPERATIONS
38 77144 Issue 8 August 2009
(4) Using thumb and forefinger, fully undo the metal
locking ring surrounding the grey plastic air flow
release, then fully open the air flow release. When
complete, tighten the locking ring. Carefully slide
the cover back in place and secure. Take care not
to trap any wires or pipes.
For the vent in the 2 litre base unit:
(5) Open the base door and remove the panel cover.
(6) Repeat step (4) for this valve.
C6000(i)
C3000, C1000, C6000v
2xvalves
Remove all securing
screws to remove the
panel cover.
Valve is located on top
of the reservoir.
To Next Page
